7600kg Road Loader LGB86 Heavy Duty Road Construction Equipment
Contact me for free samples and coupons.
Wechat: 0086 18588475571
If you have any concern, we provide 24-hour online help.x
|Size||6040X 2268 X 3760(mm)||Wheel Base||2250(mm)|
|Track||1640(mm)||Min. Ground Clearance||300(mm)|
7600kg Road Loader,
LGB86 Road Construction Equipment
· Place of Origin: China
· Model Number:LGB86
· Name: Backhoe Loader Machine
· Warranty: 3 Months
· Delivery: 10-15 Working Days
· Stock quantity: available
|Overall Operating Weight(kg)||8200||7600||Manufacturer||Feicheng Axle
|L*W*H(mm)||6230×2365×3752||6040×2268×3760||Main Transmission Type||single reduction|
|Wheel base(mm)||2200||2250||Final Reducer||Single Stage Final
|Min. Ground Clearance(mm)||300||300||Rated Loader of Axle||8.2T||7.6T|
|Loading Lifting Capacity(kg)||2500||2500||Model||YJ280||YJ280|
|Bucket Dumping Height(mm)||2650||2795||Type||Single-stage Three
|Bucket Dumping Distance(mm)||1025mm||1048||Max. Efﬁciency||84.40%|
|Digging Depth(mm)||52mm||Inlet Pressure(Mpa)||0.4-0.55|
|Backhoe Capacity(m3)||0.3||0.1-0.4||Outlet Pressure||1.2-1.5|
|Max. Digging Depth(mm)||4085||4080-4500||Cooling Method||Oil-cooling Pressure
|Swing Angle of Excavator Grab||190°||190°||GEARBOX||LGB88||LGB86|
|Max. Pulling Force(kn)||39||Type||Fixed Shaft Power
|ﬁxed shaft power
|ENGINE||LGB88||LGB86||Oil Pressure of Clutch||1373-1569|
|Model||YC4A105Z-T20||Gears||Two Gears Ahead,
Two Gears Astern
2 reverse shift
|Min. Fuel Consumption(g/kw.h)||235||Pressure of Front wheel(Mpa)||0.22||0.22|
|Max.Torque(nm)||310||Pressure of Back Wheel(Mpa)||0.22||0.22|
|STEERING SYSTEM||LGB88||LGB86||Digging Power of Excavator Grab(kn||) 46.5||46|
|Model of Steering Device||BZZ5-250||BZZ5-250||Digging Power of Dipper(kn)||31||31|
|Steering Angle||±36 o||Bucket Lifting Time(s)||5.4||6.8|
|Min. turning radius(mm)||6581||5018||Bucket Lowering Time(s)||3.1||2.5|
|Pressure of the system(Mpa)||12||Bucket Discharge Time(s)||2||1.2|
|Service Brake||Air Over Oil Caliper Brake External Type
|air over hydraulic disc on 4 wheels|
|Emergency Brake||Operation Power Implementing brake
Manual Operation Power Terminating Brake
|manual parking brake|
Packaging & Delivery :
Packaging Details: Container
PAYMENT:30% AS DEPAOISTS ,THE BALANCE SHOULD PAID BEFORE SHIPMENT.
Backhoe loader commonly known as "busy at both ends". The structure of the whole machine is to load the working device on the front end of the four-wheel drive chassis and excavate the working device on the back end, which can realize the loading and digging function on one machine. Both ends can also be installed with lifting arm, fork, pressure, hammer, sweep, crushing hammer, vibration tamper, four-in-one bucket, series of excavating bucket and dozens of different tools, to complete the carrying, digging, crushing, hoisting, clamping, disassembly, tamping, milling and other work.
The four-wheel drive chassis has strong traction, and the multi-speed gearbox enables the maximum speed of the whole machine to reach 22km/h. It can quickly reach the construction site without a trailer and efficiently complete all kinds of work.
To sum up, the two busy three characteristics: before loading after digging, a machine multi - capability, fast mobility. 1 excavator loader > 1 small loader +1 small excavator.
Our advantages :
1. We can help buyers design specific products or produce products according to buyers' design.
2. Small order acceptable.
3. Competitive price be offered.
4. Inquiry or question be answered within 12 hours.
5. Best possible after-sales service.
6. We can print logo according to buyers' requirement.
7. Stock an extensive range of spare parts.
8. Favourable geographical location.
9. Flexible pricing, offers discount and deferred payment for wholesale buyers.
10. Timely delivery.
Q1. Could you custom products?
A: We can manufacture it according to your drawings or samples.
Q2. What's your payment terms.
A: By T/T or Western Union, 100% in advance. ( large orders can be negociated)
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: 1-3 working days in general, and 7-10 days for large orders.
Q5. How can you guarantee the quality?
A: One year's warranty against B/L date.If You meet with quality problem, we promise to responsible for it.
Q6: Can we buy 1 pc of each item for quality testing?
A: Yes, we understand quality test is important and we are glad to send 1pc for quality testing.
Tags: heavy duty,agricultural,construction machinery,new construction equipment, carrying, digging, crushing, hoisting, clamping, disassembly, tamping, milling
